【React】css画一个四方位云台操控器

本期我们要做的是一个四方位云台操控器（也是遥控器），我们需要方向的 icon（自己找或者自己画～）和 ahooks 的 useInterval（ahooks 真好用啊）

# 1. 实现目标

长按可以设定每 x 秒触发一次接口
点击也可以移动
... 没了（就是这么简单）

# 2. 实现方法

	export const DIRECTION_MAP: any = {
	top: 1,
	bottom: 6,
	left: 4,
	right: 5,
	};

	function Ptz(props: IPtzProps) {
	const [interval, setInterval] = useState<any>(null);
	const directionRef = React.useRef('');

	useEffect(() => {
	enterPTZ();
	return () => {
	exitPTZ();
	};
	}, []);

	useInterval(
	async () => {
	if (directionRef.current) {
	await controlPTZ({
	direction: DIRECTION_MAP[directionRef.current],
	}).then(() => {
	//console.log (`向 ${direction} 移一点`);
	});
	}
	},
	interval,
	{ immediate: true }
	);

	const handlePress = (e: any) => {
	directionRef.current = e.target.dataset.direction;
	setInterval(interval + 1000); // 调用频率
	};

	return (
	<div className="control-wrapper">
	<div className="control-circle" />
	<div className="control-round" />
	<div
	className="control-btn control-top"
	data-direction="top"
	onMouseDown={handlePress}
	onMouseUp={() => {
	setInterval(null);
	}}
	>
	<Icon className="top-btn" type="arrowsolidlev1up" />
	</div>
	<div
	className="control-btn control-left"
	data-direction="left"
	onMouseDown={handlePress}
	onMouseUp={() => {
	setInterval(null);
	}}
	>
	<Icon className="left-btn" type="arrowsolidlev1down" />
	</div>
	<div
	className="control-btn control-bottom"
	data-direction="bottom"
	onMouseDown={handlePress}
	onMouseUp={() => {
	setInterval(null);
	}}
	>
	<Icon className="bottom-btn" type="arrowsolidlev1down" />
	</div>
	<div
	className="control-btn control-right"
	data-direction="right"
	onMouseDown={handlePress}
	onMouseUp={() => {
	setInterval(null);
	}}
	>
	<Icon className="right-btn" type="arrowsolidlev1up" />
	</div>
	</div>
	);
	}

	export default Ptz;

然后是最主要的 css

	.control-wrapper {
	position: absolute;
	bottom: 60px;
	right: 40px;
	width: 150px;
	height: 150px;
	border-radius: 50%;
	// background-color: rgba(0, 0, 0, 0.65);


	.top-btn{
	position: absolute;
	top: 0;
	left: 50%;
	transform: translate(-50%, 24px) rotate(45deg);
	display: flex;
	align-items: center;
	justify-content: center;
	box-sizing: border-box;
	color: rgba(255,255,255, .75);
	z-index: 2;
	pointer-events: none;
	}

	.left-btn{
	position: absolute;
	top: 50%;
	left: 0;
	transform: translate(24px, -50%) rotate(45deg);
	display: flex;
	align-items: center;
	justify-content: center;
	color: rgba(255,255,255, .75);
	z-index: 2;
	box-sizing: border-box;
	pointer-events: none;
	}

	.bottom-btn {
	position: absolute;
	bottom: 0;
	left: 50%;
	transform: translate(-50%, -24px) rotate(-45deg);
	display: flex;
	align-items: center;
	justify-content: center;
	color: rgba(255,255,255, .75);
	z-index: 2;
	box-sizing: border-box;
	pointer-events: none;
	}
	.right-btn {
	position: absolute;
	top: 50%;
	right: 0;
	transform: translate(-24px, -50%) rotate(45deg);
	display: flex;
	align-items: center;
	justify-content: center;
	color: rgba(255,255,255, .75);
	z-index: 2;
	box-sizing: border-box;
	pointer-events: none;
	}

	.control-btn {
	position: absolute;
	width: 62px;
	height: 62px;
	display: flex;
	align-items: center;
	justify-content: center;
	z-index: 1;
	box-sizing: border-box;
	// transition: all .3s linear;
	// background-color: red;
	background-color: rgba(0, 0, 0, 0.65);
	&::after{
	content: '';
	position: absolute;
	width: 62px;
	height: 62px;
	z-index: 1;
	}
	}
	.control-top {
	top: 0;
	left: 50%;
	transform: translateX(-50%) rotate(-45deg);
	border-radius: 0 100% 0 0;
	&:hover {
	.top-btn{
	color: rgba(255,255,255, 1);
	}
	}
	&:hover:after{
	background: rgba(255, 255, 255, 0.1);
	}
	}
	.control-top:before {
	transform: translate(30%, -25%);
	}
	.control-top:after {
	left: 0;
	bottom: 0;
	border-radius: 0 100% 0 0;
	}
	.control-bottom {
	left: 50%;
	bottom: 0;
	transform: translateX(-50%) rotate(45deg);
	border-radius: 0 0 100% 0;
	&:hover {
	.bottom-btn{
	color: rgba(255,255,255, 1);
	}
	}
	&:hover::after{
	background: rgba(255, 255, 255, 0.1);
	}
	}
	.control-bottom:before {
	transform: translate(25%, 25%) rotate(90deg);
	}
	.control-bottom:after {
	top: 0;
	left: 0;
	border-radius: 0 0 100% 0;

	}
	.control-left {
	top: 50%;
	left: 0;
	transform: translateY(-50%) rotate(45deg);
	border-radius: 0 0 0 100%;
	&:hover {
	.left-btn{
	color: rgba(255,255,255, 1);
	}
	}
	&:hover::after{
	background: rgba(255, 255, 255, 0.1);
	}
	}
	.control-left:before {
	transform: translate(-25%, 30%) rotate(180deg);
	}
	.control-left:after{
	right: 0;
	top: 0;
	border-radius: 0 0 0 100%;
	}
	.control-right {
	top: 50%;
	right: 0;
	transform: translateY(-50%) rotate(45deg);
	border-radius: 0 100% 0 0;
	&:hover {
	.right-btn{
	color: rgba(255,255,255, 1);
	}
	}
	&:hover::after{
	background: rgba(255, 255, 255, 0.1);
	}
	}
	.control-right:before {
	transform: translate(30%, -25%);
	}
	.control-right:after {
	left: 0;
	bottom: 0;
	border-radius: 0 100% 0 0;
	}
	.control-round {
	position: absolute;
	top: 50%;
	left: 50%;
	transform: translate(-50%, -50%);
	width: 56.9px;
	height: 56.9px;
	background: #7C7C7C;
	border-radius: 50%;
	z-index: 3;
	}
	}

着重讲一下 pointer-events 这个属性

需要加上 pointer-events: none ， none 元素永远不会成为鼠标事件的 target (en-US)。但是，当其后代元素的 pointer-events 属性指定其他值时，鼠标事件可以指向后代元素，在这种情况下，鼠标事件将在捕获或冒泡阶段触发父元素的事件侦听器。

否则点击到 icon 的时候是没有方向的，也就无法调用接口。
